COMI Landscape Lighting 1FS-series is designed for Ceiling Mounting down light and offers various design possibilities in architectural illumination and provides even and pleasant light distribution suitable for villlas, parks, squares, garages and residential areas and etc.
Features and benefits:
▪ Wall mounting ceiling down light.
▪ 1piece Osram or Cree COB LED.
▪ Color Temperature: 3000K, 4000K, 6000K.
▪ CRI: Ra>80.
▪ Input:220-240VAC
▪ Beam Angle: 20°, 38° (Full angle).
▪ Adjustability:Fixed.
▪ Average life time: 30000hurs@70% lumen depreciation.
▪ Finished: Optional Grey or black electrostatic powder coating.
▪ Easy wall surface ceiling mounting and maintenance.
▪ Protection class:IP65.
▪ 2 Years warranty.
Material Specifications:
| Housing |
12 Die-casting grey or black powder coated aluminum. T=60-80μm. Adhesion of ISO class 1/ASTM class 4B |
| Front Cover |
12 Die-casting grey or black powder coated aluminum, T=20-30μm Adhesion of ISO class 1/ASTM class 4B |
|
Gasket |
Molding shaped silicone seal |
| Reflector |
Optical Reflector efficiency≥90% |
| LED | 1piece OSRAM or CREE COB LED |
| Driver (included) |
Integrated Constant current LED Driver |
|
Operating Temperature |
-20℃~45℃ |
Technical Specifications:
|
Item Number
|
Dimension (L×W×H)(mm) |
Light Source
|
CRI(Ra)
(White color) |
Reflector
|
Beam
Angle |
Input Voltage
(V) |
Typical Operating
Current(mA) |
Typical Power
Consumption(W) |
Typical
Luminance(lm) |
IK |
|
R1FSA0105
|
90×90×140 |
1×5W OSRAM |
Ra>80
|
Yes
|
30°
|
220/240
|
23
|
5W
|
Cool white=492
Warm white=418 |
06
|
|
R1FSA0107 |
90×90×140 |
1×7W OSRAM COB LED (Single Color) |
Ra>80 |
Yes |
30° |
220/240 |
32 |
7W |
Cool white=672 Warm white=571 |
06 |
|
R1FSB0110 |
120×120×140 |
1×10W OSRAM COB LED (Single Color) |
Ra>80 |
Yes |
30° |
220/240 |
46 | 10W |
Cool white=963 Warm white=812 |
06 |
|
R1FSC0112 |
150×150×135 |
1×12W OSRAM COB LED (Single Color) |
Ra>80 |
Yes |
30° |
220/240 |
55 | 12W |
Cool white=1150 Warm white=967 |
06 |
|
R1FSD0115 |
150×150×140 |
1×15W OSRAM COB LED (Single Color) |
Ra>80 |
Yes |
30° |
220/240 |
68 | 15W |
Cool white=1354 Warm white=1146 |
06 |
Notes:
1. CCT(K): 3000K, 4000K, 6000K.
2. Specifications are subjected to change without notice
